Atlas PRIME Fuel Management System

Commercial and fleet fueling reimagined

The Atlas® PRIME is a fully integrated Fuel Controller and dispenser together in one unit. The newest Gasboy development integrates the Gasboy authorization terminal into the Atlas electronic dispenser platform. Equipped with a large, user-friendly, 40-key full alpha-numeric keypad with a 4.3" high-brightness LCD color screen which allows for full fleet management directly from the pump. The integrated unit includes MiFare contactless reader and an insert magnetic card reader, with optional HID reader for multiple authorization methods. The Atlas PRIME is also fully integrated with the Gasboy FuelPoint® PLUS automated fueling technology. The Atlas PRIME can operate as a stand-alone or remote terminal.

Benefits of Atlas PRIME

Driver Friendly User Interface

The Atlas PRIME allows for the most common authentication methods for both operator and vehicle.  Built-in authorization methods include MiFare contactless tag reader, card reader for proprietary cards, and a full alphanumeric keypad.  HID readers are available as an option.

Learn More

Integrated Fuel Management

Gasboy Atlas PRIME merges the latest fueling control technology with trusted Gasboy Atlas fuel dispensers. Each fueling position has its own integrated user interface for authorizing transactions and collecting driver and vehicle information.

Learn More

Improved Fueling Experience

The Atlas PRIME point-of-use fuel authorization terminal provides a faster, safer, and more intuitive fueling experience at commercial fleet fueling sites. Separate fuel control pedestals are not needed at Atlas PRIME locations which simplifies installation.

Learn More

Authorization At Your Fingertips

Many fleet fueling sites have separate dispensers and fuel management pedestals.  For the driver, this can be confusing and inefficient.  Atlas PRIME's integrated fuel controls provide a quick and efficient fueling experience.  The driver simply authorizes the transaction at the pump and begins fueling.   When driver productivity is important to your organization, chose Atlas PRIME for your fueling operation.

Reduce Installation Costs

Besides the driver experience, pedestal-controlled forecourts can produce challenges with installation. Laying cable/wire to connect dispensers with pedestals are costly and time consuming.  Atlas PRIME installations with integrated fuel controls and dispensers save installers $1,500 to $3,000 on average per pedestal.

Understanding what dispenser communication goes with what pump interface on the fuel controller is not always apparent.  With Atlas PRIME's integrated fuel controls, installers avoid mistakes with pump interfaces that can create additional installation expense.

Condensed Footprint

Since there is no additional fuel management pedestal to install, Atlas PRIME dispensers have a smaller footprint at your fueling facility.

How will Atlas PRIME integrate into your business?

View FAQs

Atlas PRIME Product Specifications

Fuel Authorization Terminal
  • 4.3" multimedia color display
  • Full alphanumeric 40 key keyboard
  • Addressable soft keys
  • Contactless MiFare cards and 125K tag reader
  • Horizontal insert magnetic card reader for fuel and fleet cards
  • Built-In Wireless Gateway for use with Gasboy FuelPoint® PLUS wireless vehicle ID system
  • Two-stage authorization option for validation of driver and vehicle with any combination RFID tag, HID tag, card reader, FuelPoint® PLUS, and keypad
In-Dispenser Controller
  • Intel Atom E3800 series processor
  • 2GB/4GB DDR3L system memory
  • Linux based operating system
HID Reader
  • Optional HID multiCLASS SE PR40 Reader
    • 125kHz contactless cards supported
    • HID Prox®, Indala® Prox, Dorado® Prox, and EM Prox legacy contactless credentials
    • 13.56 MHz contactless smart cards supported iCLASS Seos®, iCLASS SE, iCLASS®, MiFare® Classic, and MiFare DESFire®EV1
  • Real-time monitoring of refueling and tank levels, delivery and inventory reconciliation
  • Local account management supporting up to o 25,000 off-line transactions
  • 50,000 devices (vehicles & drivers)
  • Vehicle controls including fuel type restrictions, maximum daily transactions and volume, mileage and odometer restrictions.
  • Employee controls including maximum daily transactions and volume
  • UL
  • cUL
  • FCC
  • Parts and Labor coverage for 12 months from installation
